Technical Documents
Specifications
Brand
Texas InstrumentsProduct Type
Voltage Reference
Package Type
SOT-23
Reference Voltage
3V
Reference Type
Fixed
Initial Accuracy
±1 %
Temperature Coefficient
20 ppm/°C
Mount Type
Surface
Topology
Shunt
Output Current
15mA
Maximum Input Voltage
5V
Pin Count
3
Minimum Operating Temperature
-40°C
Maximum Operating Temperature
85°C
Height
1mm
Length
2.92mm
Standards/Approvals
No
Series
LM4040
Load Regulation
8 mV
Automotive Standard
No
Minimum Input Voltage
3V
Output Type
Fixed
Product Details
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
31.70 MOP
6.348 MOP Each (In a Pack of 5) (ex VAT)
Standard
5
31.70 MOP
6.348 MOP Each (In a Pack of 5) (ex VAT)
Stock information temporarily unavailable.
Standard
5
| quantity | Unit price | Per Pack |
|---|---|---|
| 5 - 745 | 6.348 MOP | 31.74 MOP |
| 750 - 1495 | 6.204 MOP | 31.02 MOP |
| 1500+ | 6.101 MOP | 30.50 MOP |
