Technical Documents
Specifications
Brand
Texas InstrumentsProduct Type
Line Transceiver
Logic Function
Driver & Receiver
IC Type
Dual Channel Transceiver
Input Type
Single Ended
Mount Type
Surface
Package Type
SOIC
Minimum Supply Voltage
3V
Pin Count
16
Maximum High Level Output Current
-1mA
Maximum Supply Voltage
5.5V
Maximum Low Level Output Current
1.6mA
Maximum Propagation Delay Time @ CL
300μs
Minimum Operating Temperature
-40°C
Maximum Operating Temperature
85°C
Height
2.65mm
Length
10.5mm
Standards/Approvals
No
Series
MAX3232
Supply Current
1mA
Automotive Standard
No
Product Details
Stock information temporarily unavailable.
71.30 MOP
14.262 MOP Each (In a Pack of 5) (ex VAT)
Standard
5
71.30 MOP
14.262 MOP Each (In a Pack of 5) (ex VAT)
Stock information temporarily unavailable.
Standard
5
| quantity | Unit price | Per Pack |
|---|---|---|
| 5 - 5 | 14.262 MOP | 71.31 MOP |
| 10 - 15 | 13.932 MOP | 69.66 MOP |
| 20+ | 13.685 MOP | 68.42 MOP |
