Technical Documents
Specifications
Brand
Texas InstrumentsProduct Type
Line Transceiver
Logic Family
SN75
Logic Function
Line Transceiver
IC Type
Line Transceiver IC
Number of Channels
1
Input Type
Differential
Output Type
Differential
Polarity
Non-Inverting
Mount Type
Surface
Package Type
SOIC
Minimum Supply Voltage
3V
Pin Count
8
Maximum Supply Voltage
3.6V
Maximum High Level Output Current
-8mA
Maximum Low Level Output Current
8mA
Maximum Propagation Delay Time @ CL
100ns
Minimum Operating Temperature
-40°C
Maximum Operating Temperature
125°C
Standards/Approvals
No
Series
SN65HVD7
Height
1.75mm
Length
5mm
Supply Current
60mA
Automotive Standard
No
Product Details
A range of High Speed RS-485 Line Drivers, Receivers and Transceivers from Texas Instruments with data rates of 10 Mbit/s or over.
Stock information temporarily unavailable.
179.90 MOP
35.985 MOP Each (Supplied in a Tube) (ex VAT)
Production pack (Tube)
5
179.90 MOP
35.985 MOP Each (Supplied in a Tube) (ex VAT)
Stock information temporarily unavailable.
Production pack (Tube)
5
| quantity | Unit price | Per Tube |
|---|---|---|
| 5 - 15 | 35.985 MOP | 179.92 MOP |
| 20 - 35 | 35.058 MOP | 175.29 MOP |
| 40+ | 34.542 MOP | 172.71 MOP |
