Technical Documents
Specifications
Brand
Texas InstrumentsLogic Family
LS
Product Type
Buffer & Line Driver
Logic Function
Buffer, Driver
Number of Channels
6
IC Type
Buffer & Line Driver IC
Input Type
Single Ended
Output Type
Open Collector
Polarity
Inverting
Mount Type
Surface
Package Type
SOIC
Minimum Supply Voltage
4.75V
Pin Count
14
Maximum Supply Voltage
5.25V
Maximum High Level Output Current
-0.25mA
Maximum Propagation Delay Time @ CL
8ns
Maximum Low Level Output Current
40mA
Minimum Operating Temperature
0°C
Maximum Operating Temperature
70°C
Standards/Approvals
No
Series
SN74LS06
Height
1.75mm
Length
8.75mm
Automotive Standard
No
Supply Current
60mA
Product Details
Stock information temporarily unavailable.
46.80 MOP
9.357 MOP Each (In a Pack of 5) (ex VAT)
Standard
5
46.80 MOP
9.357 MOP Each (In a Pack of 5) (ex VAT)
Stock information temporarily unavailable.
Standard
5
| quantity | Unit price | Per Pack |
|---|---|---|
| 5 - 10 | 9.357 MOP | 46.78 MOP |
| 15 - 20 | 9.13 MOP | 45.65 MOP |
| 25+ | 8.986 MOP | 44.93 MOP |
