Technical Documents
Specifications
Brand
Texas InstrumentsLogic Family
SN75
Product Type
Line Transceiver
Logic Function
Line Transceiver
Number of Channels
2
IC Type
Line Transceiver IC
Input Type
Differential
Output Type
Differential
Polarity
Non-Inverting
Mount Type
Through Hole
Package Type
PDIP
Minimum Supply Voltage
4.75V
Pin Count
16
Maximum High Level Output Current
-60mA
Maximum Supply Voltage
5.25V
Maximum Propagation Delay Time @ CL
35ns
Minimum Operating Temperature
-20°C
Maximum Low Level Output Current
60mA
Maximum Operating Temperature
85°C
Height
5.08mm
Length
19.69mm
Standards/Approvals
No
Width
6.6mm
Series
SN751178
Supply Current
110mA
Automotive Standard
No
Product Details
A range of High Speed RS-485 Line Drivers, Receivers and Transceivers from Texas Instruments with data rates of 10 Mbit/s or over.
Stock information temporarily unavailable.
66.70 MOP
66.67 MOP Each (Supplied in a Tube) (ex VAT)
Production pack (Tube)
1
66.70 MOP
66.67 MOP Each (Supplied in a Tube) (ex VAT)
Stock information temporarily unavailable.
Production pack (Tube)
1
| quantity | Unit price |
|---|---|
| 1 - 6 | 66.67 MOP |
| 7 - 12 | 65.13 MOP |
| 13+ | 63.07 MOP |
