Technical Documents
Specifications
Brand
VishayMount Type
Surface
Product Type
Optocoupler
Maximum Forward Voltage
1.6V
Number of Channels
1
Number of Pins
4
Package Type
Mini-Flat
Input Current Type
DC
Typical Rise Time
3μs
Maximum Input Current
60mA
Isolation Voltage
3.75kVrms
Minimum Operating Temperature
-40°C
Maximum Current Transfer Ratio
160%
Maximum Operating Temperature
100°C
Minimum Current Transfer Ratio
80%
Typical Fall Time
4.7μs
Standards/Approvals
FIMKO:FI EN 60950-1:2006, UL1577, BS EN60950-1:2006, BSI:BS EN60065:2002, cUL CSA 22.2 bulletin 5A, DIN EN 60747-5-5 (VDE 0884-5)
Series
TCMT
Automotive Standard
No
Product Details
The TCMT410. series consist of a phototransistor optically coupled to a gallium arsenide infrared-emitting diode in a 16 pin (quad channel) package.
UL, CSA, VDE
Stock information temporarily unavailable.
29.70 MOP
2.968 MOP Each (Supplied as a Tape) (ex VAT)
Production pack (Tape)
10
29.70 MOP
2.968 MOP Each (Supplied as a Tape) (ex VAT)
Stock information temporarily unavailable.
Production pack (Tape)
10
| quantity | Unit price | Per Tape |
|---|---|---|
| 10 - 740 | 2.968 MOP | 29.68 MOP |
| 750 - 1490 | 2.906 MOP | 29.06 MOP |
| 1500+ | 2.844 MOP | 28.44 MOP |
